Description

Product Description : AQUAGROUP’S “TEXMO” Single phase Self priming Pumps are side channel centripetal pumps. They are convenient, rugged and reliable pumps for the household, they have proven their performance over many decades. This pump has got good self priming action even with air entrapped. Product Data : PARTICULARS = DETAILS Power Range = 0.5HP to 1.0 HP Voltage Range = 200V – 240V, 50Hz, AC Single phase Speed = 1420 RPM Motor Type = High torque Capacitor start motor for DMS series / High torque Capacitor start and Capacitor run motor for DMS N series Head = Maximum 36 M Discharge = Maximum 59 LPM Operating Pressure = Maximum 15 bar Applications : All applications requiring Self priming action up to 8 meters Overhead storage water- tank filling Car washing Water supply to commercial establishments like Hotels, Lodges and Hospitals Gardening and small farm Irrigations Home Pressure Boosting Applications Filter point pumping Features : Rugged single phase TEFC motor with dynamically balanced rotor Suitable for 200 – 240 V, 50 Hz power supply Rigid and accurate cast iron castings Highly wear resistant bronze impeller Carbon Vs Ceramic mechanical seal Material of construction PARTCULARS = DETAILS Stator Frame = Cast Iron Bearings = Deep groove ball bearings Rotor shaft = Carbon Steel Shaft sleeve = Bronze Casing = Cast Iron Cover dome = Cast Iron Impeller = Bronze Sealing Arrangements = Carbon Vs Ceramic Mechanical seal.
